High Strength Galvanized Chain Link Panels Temporary Panel Fence For Commercial

    Buy cheap High Strength Galvanized Chain Link Panels Temporary Panel Fence For Commercial from wholesalers

    Buy cheap High Strength Galvanized Chain Link Panels Temporary Panel Fence For Commercial from wholesalers
    • Buy cheap High Strength Galvanized Chain Link Panels Temporary Panel Fence For Commercial from wholesalers

    High Strength Galvanized Chain Link Panels Temporary Panel Fence For Commercial

    Ask Lasest Price
    Brand Name : TOPFENCE™-galvanized temporary fence
    Model Number : 2100mm*2400mm*3.0mm3.8mm&4.00mm thick 1.4mm,1.3mm ,1.8mm,2.00mm
    Certification : AS4687-2007
    Price : 11.88usd-38.88usd
    Payment Terms : TT30%deposit balance70% at sight finished products pictures
    Supply Ability : 10000 pieces per month
    Delivery Time : 3 days
    • Product Details
    • Company Profile

    High Strength Galvanized Chain Link Panels Temporary Panel Fence For Commercial

    Easy temp fencing panels galvanized standard to be 14 microns pr-gal 2.1m*3.3m height mesh 60mm*150mm*dia3.00mm


    The manufacturing process uses hand welding for optimum strength with an average of over 70 micron hot dipped galvanised finish. We use the highest quality material specification, incorporating:
    1) Frame - 32mm diameter horizontal and vertical pipes with a min 2mm wall thickness
    2) Mesh - 4mm horizontal and vertical wire with 150mm x 60mm spacing's


    Temporary fence

    Wire Gauge

    3.0mm, 3.2mm, 3.5mm, 4.0mm, 4.5mm or as request

    OpeningMesh

    60*150mm, 60*75mm,75*75mm, 75*100mm,
    50*100mm,50*150mm, etc

    Fence frame pipe

    32mm O.D.,38mm O.D., 40mm O.D., 42mm O.D., 48mm O.D. etc

    Regular size

    2.1*2.4m, 1.8*2.4m, 1.8*2.9m, 2.1*2.9m, or as request

    Plastic feet

    600*220*150mm, or 580*245*130mm

    Frame wall thickness

    1.8mm and 2.0mm

    Surface treatment Hot-dipped galvanized or electric galvanized

    Different specifications are available according to your needs

    2) Popular sizes of australia temporary construction fence:

    Type

    Australia temporary fence

    Wire Diameter

    4.0mm

    Mesh Opening

    60x150mm

    Panel Size

    2100x2400mm

    Vertical Pipe Size

    O.D. 32mmx2.0mm(wall thickness)
    150mm left at top and bottom

    Horizontal Pipe Size

    O.D. 32mmx2.0mm(wall thickness)

    Base Plate

    600x220x150mm

    Package


    Steel pallet


    Main markets: Australia, Canada, America, European countries, and Asia countries.


    3. Temporary Fence Feet
    Plastic/Concrete Fence Feet
    Our Plastic/Concrete Fence Feet are a high quality, heavy duty, long life product.
    Your Temporary Fence will look great and be safer with these high visibility coloured feet. They are easier to see which makes them safer as they are less likely to be a tripping hazard for the public.
    4. Temporary Fence Clamps

    High quality Temporary Fence Clamps used to secure the panels together.
    Hot Dipped Galvanised to Australian Standard - 42 Microns.
    Specially moulded and 4mm thick for additional strength.
    5. Temporary Fence Stays

    High quality Temporary Fence Stays used to support the temporary fence in high wind areas.
    Hot Dipped Galvanised to Australian Standard - 42 Microns.
    Specially designed for extra strength so fence stands up in very high winds.
    Each Stay requires 3 Clamps and 3 Plastic Feet.
    7. Temporary metal fence panels benefits:

    1) . Quick and easy to install and can be easily re-located
    2) . Protects your valuable assets and protects you against Public Liability claims
    3) . Hinged gates can be attached to enable vehicular and machinery access
    4) . Panel stabilisers used to ensure sturdy fences on long runs or wind prone areas.
    5) . The new bracing system further ensures the integrity of the fence system in areas
    prone to high winds
    6) . Fence extensions are available on the Industrial/Event panel
    7) . Industry regulations in place with CFMEU, C+BUS, Incolink, Co-Invest etc

    8. Why Our Heavy Duty Temporary Fence Panels are the Best



    Our top of the range panel is manufactured for its robustness in remote and extreme climates. These products withstand these environments and are best suited for the Resource and Hire industries . Our flagship panel specification:

    • Anti -climb mesh infill

    • 360° weld between the vertical & horizontal pipe

    • Horizontal pipe ends crimped for increased strength.

    • Above Industry Benchmark in thickness of galvanising

    • 1.94 Metre Top Horizontal Pipe for extra security
