2100mm*2400mm construction mobile Fencing Panels Mesh 60mm*210mm*3.00mm wire HDG pre-galvanized treated

Our industrial style temporary fence panels are ideal for events, construction and building sites. These industrial panels can withstand high winds and pressure placed against the fence. The two part plastic blocks are both easy to transport and assemble.

1. Temporary fencing standard Specification:

Panel size:2100mm(H)×2400mm(L) 1800mm(H)×2100mm(L)
Pipe diameter:32mm
Infill Mesh:60mm×150mm ,50mm×50mm,50mm×150m
Diameter wire:3.5mm or 4mm

Finish HDG: Hot Dipped galvanized to Australian Standard,Wire 28 microns,pipe 42 microns zinc thick.
Main markets: Australia. New Zealand etc

2. Temporary fening panels

• Anti-climb mesh
• Quick and easy to install and can be easily re-located
• Protects your valuable assets and protects you against Public Liability claims
• Hinged gates can be attached to enable vehicular and machinery access
• Panel stabilisers used to ensure sturdy fences on long runs or wind prone areas.
• The new bracing system further ensures the integrity of the fence system in areas prone to high winds
• Fence extensions are available on the Industrial/Event panel
• Industry regulations in place with CFMEU, C+BUS, Incolink, Co-Invest etc

3. Temporary Fence Plastic Feet

Our Plastic/Concrete Fence Feet are a high quality, heavy duty, long life product.
Your Temporary Fence will look great and be safer with these high visibility coloured feet. They are easier to seewhich makes them safer as they are less likely to be a tripping hazard for the public.
Length: 560mm Width: 245mm Height: 130mm

4. Temporary Fence Clamps

High quality Temporary Fence Clamps used to secure the panels together.
Hot Dipped Galvanised to Australian Standard – 42 Microns.
Specially moulded and 4mm thick for additional strength.

5. Temporary fence application:

Our temporary fencing systems can be quickly and easily installed, no need to dig holes or lay foundations. Temporary Fence sales services offer safe and secure solutions for:

• Temporary fence for construction sites and private property
• Temporary fence for residential housing sites
• Temporary fence and crowd control barriers for major public & sports events, concerts, festivals, gatherings… etc.
• Temporary safety fencing for swimming pools
• And many other uses…

• TEMPORARY FENCE BASE

Blow molding Base Version HDPE materials						Suit Pipes
Size	600 x 228 x 150mm	Size	620 x 230 x 130mm	Size	600 x 228mm x 150mm	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
Materials	HDPE	Materials	HDPE	Materials	HDPE
Finish	UV 3 -UV5	Finish	UV3-UV5	Finish	UV3-UV5
Colors	Orange, Green ,Yellow etc	Colors	Orange, Green ,Yellow etc	Colors	Orange ,Green ,Yellow etc
Weight	After filled 27kg-29kg	Weight	After filled 27kg-28kg	Weight	29kg
Design	Australia	Design	Australia	Design	Australia
Clamp	100mm center to center	Clamp	90mm center to center	Clamp	80mm

Blow molding Base Version HDPE materials						Suits pipes
Size	615mm x 230mm x 100mm	Size	620 x 230 x 130mm	Size	600 x 220mm x 150mm	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
Materials	HDPE	Materials	HDPE	Materials	HDPE
Finish	UV 3 -UV5	Finish	UV3-UV5	Finish	UV3-UV5
Colors	Orange, Green ,Yellow etc	Colors	Orange, Green ,Yellow etc	Colors	Orange ,Green ,Yellow etc
Weight	After filled 27kg	Weight	After filled 27kg-28kg	Weight	29kg
Design	Australia	Design	Australia	Design	Australia
Clamp	100mm center to center	Clamp	100mm center to center	Clamp	100mm

	Temporary Fencing Block -Blow Molding fill Water		Suit pipes
	Materials	High density poly-ethylene (HDPE)	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
	Color	Green ,Yellow ,Black
	Weight	26kg after filled warer
	Packing	Stacking together as pallet
	Treatment	UV 3 ,UV 4 UV 5
	Size of foot	600 x 220 x130mm
	Packing	Metal pallet

	Temporary Fencing Block --Recycled Rubber Foot		Suit pipes
	Materials	Recycled rubber foot	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
	Color	Green ,Yellow ,Black
	Weight	19KG
	Packing	Stacking together as pallet
	Treatment	Oil painted
	Size of foot	767 x 192 x 126mm
	Packing	Metal pallet

• TEMPORART FENCE CLMAP/CLIP

Temporary Fencing Clamp-100TYPE
	Thickness	4.00mm
	Center distance	100mm ( pipes center to center) /OVERALL LENGTH120MM
	Technical	Punched
	Materials	Q195 Q235 steel
	Design	Australia
	Made Country	China
	Treatment	14 microns ,42 microns hot dipped galvanized electrostatic powder coated
	Application	Secured Temporary Fence panels ,and Bracket ,Stay ,Gate
	Weight	0.45kg /set 2 pairs included big caps bolt and nuts

Temporary Fencing Clamp-90TYPE
	Thickness	4.00mm
	Center distance	90mm ( pipes center to center) /OVERALL LENGTH 110MM
	Technical	Punched
	Materials	Q195 Q235 steel
	Design	Australia
	Made Country	China
	Treatment	14 microns ,42 microns hot dipped galvanized electrostatic powder coated
	Application	Secured Temporary Fence panels ,and Bracket ,Stay ,Gate
	Weight	0.40kg /set 2 pairs included big caps bolt and nuts

Temporary Fencing Clamp-80TYPE
	Thickness	4.00mm
	Center distance	80mm ( pipes center to center) /OVERALL LENGTH 100MM
	Technical	Punched
	Materials	Q195 Q235 steel
	Design	Australia
	Made Country	China
	Treatment	14 microns ,42 microns hot dipped galvanized electrostatic powder coated
	Application	Secured Temporary Fence panels ,and Bracket ,Stay ,Gate
	Weight	0.35kg /set 2 pairs included big caps bolt and nuts

• TEMPORARY FENCE PANELS

Cheapest Temporary Fence -14 microns pre-galvanized silver painted
Design	New Zealand
Made	China
Specification
Height	2000mm
Width	2200mm
Pipes	OD 32mm x 1.20mm
Infill mesh	60mm x 150mm
Diameter	3.00mm
Standard	AS&NZS 4687-2007
Packing	Bulk Load or packing in metal pallet
20gp load panels	320 pieces temporary fencing panels only
20 set load set	300 set ( 1pcs panel+1pcs foot +1pcs clamp)
40hc load panels	800 pieces temporary fencing panels only
40hc load set	690 sets( 1pcs panel+1pcs foot +1pcs clamp)
Weight of panel	12.00kg
Advantage	Have all functions of temporary fencing are with a cant beat cheapest price to suit less budget guys
Disadvantage	Too light duty ,pipes and wire are too weak,zinc layers is not too heavy
Service life	1 years -3 years
Colors	Silver right or electrostatic powder coated
Materials	Q235 Q195 PEE-GALVANIZED STEEL PIPES ROLLED PIPES
Welding	Two sides of temporary fencing welded by worker hand welding GMAW
PRICE

Economist Temporary Fence -14 microns per-galvanized
Design	Australia
Made	China
Specification
Height	2100mm
Width	2400mm
Pipes	OD 32mm x 1.40mm
Infill mesh	60mm x 150mm
Diameter	3.00mm
Standard	AS&NZS 4687-2007
Packing	Bulk Load or packing in metal pallet
20gp load panels	258 pieces temporary fencing panels only
20 set load set	250 set ( 1pcs panel+1pcs foot +1pcs clamp)
40hc load panels	710 pieces temporary fencing panels only
40hc load set	560 sets( 1pcs panel+1pcs foot +1pcs clamp)
Weight of panel	14.50kg
Advantage	Suit for private construction owner buy it for a middle term using also good for sale to local guys
Disadvantage	Too light duty ,pipes and wire are too weak,zinc layers is not too heavy easy to broken
Service life	1 years -3 years
Colors	Silver right or electrostatic powder coated
Materials	Q235 Q195 PEE-GALVANIZED STEEL PIPES ROLLED PIPES
Welding	Two sides of temporary fencing welded by worker hand welding GMAW
PRICE

Budget Temporary Fence -14 microns per-galvanized
Design	Australia
Made	China
Specification
Height	2100mm
Width	2400mm
Pipes	OD 32mm x 1.5
Infill mesh	60mm x 150mm
Diameter	3.5
Standard	AS&NZS 4687-2007
Packing	Bulk Load or packing in metal pallet
20gp load panels	258 pieces temporary fencing panels only
20 set load set	250 set ( 1pcs panel+1pcs foot +1pcs clamp)
40hc load panels	710 pieces temporary fencing panels only
40hc load set	560 sets( 1pcs panel+1pcs foot +1pcs clamp)
Weight of panel	17.00kg
Advantage	The one are a middle quality one,suit both of sale and hire business
Disadvantage	light duty ,pipes and wire are too weak,zinc layers is not too heavy easy to broken
Service life	1 years -3 years
Colors	Silver right or electrostatic powder coated
Materials	Q235 Q195 PEE-GALVANIZED STEEL PIPES ROLLED PIPES
Welding	Two sides of temporary fencing welded by worker hand welding GMAW
PRICE

Standard 1.80-3.80 or 2.0-4.0 version Temporary Fence --14 microns per-galvanized
Design	Australia
Made	China
Specification
Height	2100mm
Width	2400mm
Pipes	OD 32mm x 1.8mm or OD 32 x 2.00mm
Infill mesh	60mm x 150mm
Diameter	3.8mm
Standard	AS&NZS 4687-2007
Packing	Bulk Load or packing in metal pallet
20gp load panels	258 pieces temporary fencing panels only
20 set load set	250 set ( 1pcs panel+1pcs foot +1pcs clamp)
40hc load panels	710 pieces temporary fencing panels only
40hc load set	560 sets( 1pcs panel+1pcs foot +1pcs clamp)
Weight of panel	20.00kg
Advantage	Heavy duty starter the one you saw anywhere in Australia and New Zealand good for hire or sale professional looking
Disadvantage	Easy to rusting zinc layer light 14 microns
Service life	2 years -3 years
Colors	Silver right or electrostatic powder coated
Materials	Q235 Q195 PEE-GALVANIZED STEEL PIPES ROLLED PIPES
Welding	Two sides of temporary fencing welded by worker hand welding GMAW
PRICE

Standard 1.80-3.80 or 2.0-4.0 version Temporary Fence -42 microns per-galvanized

Top Fence co focused on manufacturing premium temporary fencing kit at a cost efficient rate covered with temporary fencing panels HDPE foot as well clamp system ,temporary fencing bracket ,temporary fencing gates etc, Annual we manufactured at least 50000 piece temporary fencing sold well in australia market such as brisbane ,Melbourne ,Perth ,Fremental .The products we manufactured adopt to AS 4687-2007 Standard Required .For sake of saving laborforce cost we imported welding robots from germany to eliminate the procedure not necessary to operate by workers so enable us always can pass a competitive rate .We serve more than 200 client in Australia ,among of them there are 20 regular long term clients what we achieved is casue we build complete after sale service and quality control system,our inspectors are through yearly professional training who help us to win a good repuation in local Australia .Top Fence take customers accurate requirements of market as key point of mutual profit and business success.Adquate market investigation made us to reserach and develop the temporary fencing to meet any group client requirments such as Standard Temporary Fence Classfied 14 microns /42 microns zinc layer ,Economic Temporary Fence etc
