Security Construction Fencing Panels Suit AS4687 2.1m*2.4m Mesh 60mmx150mm diameter 3.00mm ,3.5mm ,3.8mm ,4.00mm OD 42mm

TOP FENCE co temporary fence design for corrosion resistance in extreme climates in new zealand and australia all materials meet AS/NZS hot dipped galvanized standard .Construction Fencing panels with many application It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations.

4. Application

(1) Temporary fence panel to secure construction sites and private property.
(2) Temporary fencing panel of residential housing sites.

(3) Temporary fencing panel and crowd control barriers for major public. events, sports, concerts, festivals,

gatherings etc.
(4) Temporary fence panel safety fencing for swimming pools

• Options of Temporary Fencing Clamp

Temporary Fencing Clamp-100TYPE
	Thickness	4.00mm
	Center distance	100mm ( pipes center to center) /OVERALL LENGTH120MM
	Technical	Punched
	Materials	Q195 Q235 steel
	Design	Australia
	Made Country	China
	Treatment	14 microns ,42 microns hot dipped galvanized electrostatic powder coated
	Application	Secured Temporary Fence panels ,and Bracket ,Stay ,Gate
	Weight	0.45kg /set 2 pairs included big caps bolt and nuts

Temporary Fencing Clamp-90TYPE
	Thickness	4.00mm
	Center distance	90mm ( pipes center to center) /OVERALL LENGTH 110MM
	Technical	Punched
	Materials	Q195 Q235 steel
	Design	Australia
	Made Country	China
	Treatment	14 microns ,42 microns hot dipped galvanized electrostatic powder coated
	Application	Secured Temporary Fence panels ,and Bracket ,Stay ,Gate
	Weight	0.40kg /set 2 pairs included big caps bolt and nuts

Temporary Fencing Clamp-80TYPE
	Thickness	4.00mm
	Center distance	80mm ( pipes center to center) /OVERALL LENGTH 100MM
	Technical	Punched
	Materials	Q195 Q235 steel
	Design	Australia
	Made Country	China
	Treatment	14 microns ,42 microns hot dipped galvanized electrostatic powder coated
	Application	Secured Temporary Fence panels ,and Bracket ,Stay ,Gate
	Weight	0.35kg /set 2 pairs included big caps bolt and nuts

5. Main markets:

Australia ,New Zealand,European countries,Asia countries

Blow molding Base Version HDPE materials						Suit Pipes
Size	600 x 228 x 150mm	Size	620 x 230 x 130mm	Size	600 x 228mm x 150mm	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
Materials	HDPE	Materials	HDPE	Materials	HDPE
Finish	UV 3 -UV5	Finish	UV3-UV5	Finish	UV3-UV5
Colors	Orange, Green ,Yellow etc	Colors	Orange, Green ,Yellow etc	Colors	Orange ,Green ,Yellow etc
Weight	After filled 27kg-29kg	Weight	After filled 27kg-28kg	Weight	29kg
Design	Australia	Design	Australia	Design	Australia
Clamp	100mm center to center	Clamp	90mm center to center	Clamp	80mm

Blow molding Base Version HDPE materials						Suits pipes
Size	615mm x 230mm x 100mm	Size	620 x 230 x 130mm	Size	600 x 220mm x 150mm	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
Materials	HDPE	Materials	HDPE	Materials	HDPE
Finish	UV 3 -UV5	Finish	UV3-UV5	Finish	UV3-UV5
Colors	Orange, Green ,Yellow etc	Colors	Orange, Green ,Yellow etc	Colors	Orange ,Green ,Yellow etc
Weight	After filled 27kg	Weight	After filled 27kg-28kg	Weight	29kg
Design	Australia	Design	Australia	Design	Australia
Clamp	100mm center to center	Clamp	100mm center to center	Clamp	100mm

Top Fence co focused on manufacturing premium temporary fencing kit at a cost efficient rate covered with temporary fencing panels HDPE foot as well clamp system ,temporary fencing bracket ,temporary fencing gates etc, Annual we manufactured at least 50000 piece temporary fencing sold well in australia market such as brisbane ,Melbourne ,Perth ,Fremental .The products we manufactured adopt to AS 4687-2007 Standard Required .For sake of saving laborforce cost we imported welding robots from germany to eliminate the procedure not necessary to operate by workers so enable us always can pass a competitive rate .We serve more than 200 client in Australia ,among of them there are 20 regular long term clients what we achieved is casue we build complete after sale service and quality control system,our inspectors are through yearly professional training who help us to win a good repuation in local Australia .Top Fence take customers accurate requirements of market as key point of mutual profit and business success.Adquate market investigation made us to reserach and develop the temporary fencing to meet any group client requirments such as Standard Temporary Fence Classfied 14 microns /42 microns zinc layer ,Economic Temporary Fence etc
