    Corrosion - Resistant 8x12 Temporary Chain Link Fence Construction Fence Panel

    Ask Lasest Price
    Brand Name : top fence
    Model Number : chain link wire temporary construction fence panels
    Certification : ISO
    Price : 29.88 -46.88usd
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 10000 pcs per year
    Delivery Time : 14 days
    • Product Details
    • Company Profile

    Corrosion - Resistant 8x12 Temporary Chain Link Fence Construction Fence Panel

    8’H x 12’W Chain Link Temporary Fence Panel tubing 1⅝”(42mm) x 16 gauge thick Mesh spacing2½”x2½” (63mmx63mm) x 12 gauge

    TOP FENCE co temporary construction fence to protect you site with 8'x12' chain link temporary fence panels it can portect you site from outside injury and and inside working site with a higher safety,the chain wire mesh infilled full welding temporary fence frame with a flexiable to withstand external force strength,the chain link fence panels design for a fast installations in a efficinet way to pretent unauthorized persons from entering, theft and dumping constructions rubbish .Temporary chain link fence consist a 1.375 "(42mm) tubing with a standard 16 gauge thickness and a mesh spacing 2.25"x2.25"(63mmx63mm) chain link mesh aperture then take hot dipped galvanized zinc 275 wire laced allf four sides 2.25"x2.25" chain mesh opening ( also available flat bar)


    Features

    • The 8’H x 12’W Chain Link Temporary Fence Panel is constructed of 16 gauge 1-5/8" pipe with cross brace

    • Keeps pedestrians safe from accidental injury

    • Laced on all sides with chain link 2-3/8" x 11.5 gauge mesh size

    • Adaptable to a variety of configurations 6ftx12ft 6 x 12ft ,4ft ,8ft and so on


    Temporary Chain Link Fence /Construction Fence Panels Spec
    Tubing1¼”(32mm) 1⅜”(35mm) 1½”(38mm) 1⅗”(40mm) 1⅝”(42mm) 1⅞”(48mm)and so on
    Thickness of Tubing16GA/ 1.6mm thick as a standard or customized owned size
    Chain mesh aperture2”x2/”(50mm x 50mm) 2¼”x2¼”(57mmx57mm) 2⅜x2⅜(60mmx60mm) 2½”x2½” (63mmx63mm)
    Height4ft/1220mm 6ft/1820mm 8ft/2420mm
    Width12ft /3650mm was wide acceptance by market also 8ft 9ft 10ft 14ft
    Panels Size6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on
    Diameter /Gauge10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m
    Base Optional 136” length x 30” width x 8” Height /914mmx762mmx203mm
    Base Optional 236” length x 16” width x 8” Height /914mmx406mmx203mm
    Base Optional 330” length x 18” width x 8” Height /762mm x460mm x203mm
    StandardASTM A392-06
    SteelGalvanized Steel Construction
    FinishCorrosion-Resistant Zinc Coating
    Transport PackingMetal pallet Wrapped with Plastic
    HDG zinc thickness14 microns 100gram/SQM 28 microns 200 gram/SQM 42 microns 300 gram/SQM and 84 microns 600 gram/SQM

    Corrosion - Resistant 8x12 Temporary Chain Link Fence Construction Fence PanelCorrosion - Resistant 8x12 Temporary Chain Link Fence Construction Fence PanelCorrosion - Resistant 8x12 Temporary Chain Link Fence Construction Fence PanelCorrosion - Resistant 8x12 Temporary Chain Link Fence Construction Fence Panel
