Construction Fence Panels 360 full welding 2.1m*2.4m width Mesh spacing 60mm*150mm*3.8mm

We offer some of the most durable and reliable temporary fencing options on the market. It can be used in a wide range of environments. Our temporary fencing panels are designed for long life and regular use. Temporary fence panels are made using galvanized steel wire strands and welded together to form a high strength mesh. With a galvanized finish and fully welded frame, the system offers a total package for your site, giving a system that is user friendly to you and the general public.

2.Product Specification

Different specification are available according to customer's special inquiry or detailed drawing.

1. Bases:

Blow molding Base Version HDPE materials						Suit Pipes
Size	600 x 228 x 150mm	Size	620 x 230 x 130mm	Size	600 x 228mm x 150mm	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
Materials	HDPE	Materials	HDPE	Materials	HDPE
Finish	UV 3 -UV5	Finish	UV3-UV5	Finish	UV3-UV5
Colors	Orange, Green ,Yellow etc	Colors	Orange, Green ,Yellow etc	Colors	Orange ,Green ,Yellow etc
Weight	After filled 27kg-29kg	Weight	After filled 27kg-28kg	Weight	29kg
Design	Australia	Design	Australia	Design	Australia
Clamp	100mm center to center	Clamp	90mm center to center	Clamp	80mm

Blow molding Base Version HDPE materials						Suits pipes
Size	615mm x 230mm x 100mm	Size	620 x 230 x 130mm	Size	600 x 220mm x 150mm	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
Materials	HDPE	Materials	HDPE	Materials	HDPE
Finish	UV 3 -UV5	Finish	UV3-UV5	Finish	UV3-UV5
Colors	Orange, Green ,Yellow etc	Colors	Orange, Green ,Yellow etc	Colors	Orange ,Green ,Yellow etc
Weight	After filled 27kg	Weight	After filled 27kg-28kg	Weight	29kg
Design	Australia	Design	Australia	Design	Australia
Clamp	100mm center to center	Clamp	100mm center to center	Clamp	100mm

	Temporary Fencing Block -Blow Molding fill Water		Suit pipes
	Materials	High density poly-ethylene (HDPE)	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
	Color	Green ,Yellow ,Black
	Weight	26kg after filled warer
	Packing	Stacking together as pallet
	Treatment	UV 3 ,UV 4 UV 5
	Size of foot	600 x 220 x130mm
	Packing	Metal pallet

	Temporary Fencing Block --Recycled Rubber Foot		Suit pipes
	Materials	Recycled rubber foot	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
	Color	Green ,Yellow ,Black
	Weight	19KG
	Packing	Stacking together as pallet
	Treatment	Oil painted
	Size of foot	767 x 192 x 126mm
	Packing	Metal pallet

	Temporary Fencing Block - Injection Molding foot		Suit pipes
	Materials	High density poly-ethylene (HDPE)	OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm
	Color	Green ,Yellow ,Black
	Weight	30kg
	Packing	Stacking together as pallet
	Treatment	UV 3 ,UV 4 UV 5
	Size of foot	560 x 245 x 130mm
	Packing	Metal pallet

Panel braces are used to add extra support to a fence when on straight runs however other panels can also be used to brace a fence.

High quality Temporary Fence Stays used to support the temporary fence in high wind areas.

Hot Dipped Galvanized to Australian Standard – 42 Microns.

Specially designed for extra strength so fence stands up in very high winds.

Each Stay requires 3 Clamps and 3 Plastic Feet.

5.Application

Temporary Job Site/Work Site Security,Temporary Pool Fencing,Event/Function Fencing,Crowd Control Fencing

It has wide applications as a protective fence and can be used to strengthen security systems in railways, airports, highways, stadiums and other public places. It also can be used in all kinds of anti-climbing and anti-theft installations.

Top Fence co focused on manufacturing premium temporary fencing kit at a cost efficient rate covered with temporary fencing panels HDPE foot as well clamp system ,temporary fencing bracket ,temporary fencing gates etc, Annual we manufactured at least 50000 piece temporary fencing sold well in australia market such as brisbane ,Melbourne ,Perth ,Fremental .The products we manufactured adopt to AS 4687-2007 Standard Required .For sake of saving laborforce cost we imported welding robots from germany to eliminate the procedure not necessary to operate by workers so enable us always can pass a competitive rate .We serve more than 200 client in Australia ,among of them there are 20 regular long term clients what we achieved is casue we build complete after sale service and quality control system,our inspectors are through yearly professional training who help us to win a good repuation in local Australia .Top Fence take customers accurate requirements of market as key point of mutual profit and business success.Adquate market investigation made us to reserach and develop the temporary fencing to meet any group client requirments such as Standard Temporary Fence Classfied 14 microns /42 microns zinc layer ,Economic Temporary Fence etc
