    Portable Temporary Fence Panels , Temporary Wire Fence High Strength

    Ask Lasest Price
    Brand Name : TOPFENCE®
    Model Number : 1800MM X 2400MM ,2100MM X2400MM ,2100MM X 3300MM AND 3500MM
    Certification : AS4687-2007
    Price : 12.88USD-38.88USD
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 5000 pcs per week
    Delivery Time : 14 work days
    • Product Details
    • Company Profile

    Portable Temporary Fence Panels , Temporary Wire Fence High Strength

    Temporary Fence made in TOPFENCE incoperate a anti climb mesh in a 60mm x 150mm diameter 4.00mm and 4.00mm ,all steel wire and tubing was Q235 steel was one of best steel materials for welding construction fencing panels ,productions of steel temporary fencing is mianly covered several steps list as follow


    • raw materials prepared

    • infill mesh welding

    • saw tubing in moderate dimension

    • welding infill mesh attached to tubing

    • HDG or silver painted as per order required


    Obvious the process of productions looks rather easy and no any high technology but each steps do difference jobs will lead to price of fencing panels in a huge difference


    Raw materials welding temporary fencing panels in china mainly covered Q195 and 235,the decent manufactueers like TOP FENCE was always prefer Q235 even per tons we pay extra 20USD-30USD but for us machine and workers as end user of temporary fencing prefer the materials off Q235 ,simply speaking better strength than Q195

    pre-galvanized HDG wire and black wire is usual two types of materials we use them welding infilled mesh of fencing panels due to a price reason most of supplier will take HDG wire as a priority casue incoperate with pre-galvanized tubing or full HDG pipes then they can call it be HOT DIPPED GALVANIZED temporary fence but all supplier it is not cause it NO dipped in zinc pool process of or just steel pipes dipped into zinc pool ,the mesh are pre-galvanized .So why ? casue all of these related cost .


    In NZ and AU when the people buy temporary fencing from china ,they are always say 42 microns but do there are several types can be up to 42microns temp fence


    1. black steel tubing pls black steel mesh dipped into zinc pool then covered a minimum 42 microns -84 microns thickness

    2. Hot dipped galvanized pipes the one we bought from STEEL manufactuers was finished hot dipped galvanized ,the testing reuslt is 42 microns then plus a pre-galvanized infill mesh 14 microns or 42 microns then still be called 42 microns temporary fencing ,due to by current technical checking zinc thickness of steel wire are hard

    3. Full hdg mesh 42 microns plus 42 microns tubing then welding together still can be called 42 microns hdg

    Excluded 1 all 2 and 3 is not real 42 microns temporary fencing panels cause just some process was dipped into zinc pool when welding will break zinc layer so in top fence we dont called it real 42 microns hdg temp fence panels ,if you are interested more about informations like this welcome to email us bob@wiremeshfence.com



    Standard 1.80-3.80 or 2.0-4.0 version Temporary Fence -42 microns full hot dipped galvanized

    Design

    Australia

    Made

    China

    Specification

    Height

    2100mm

    Width

    2400mm

    Pipes

    OD 32mm x 1.8mm or OD 32mm x 2.00mm

    Infill mesh

    60mm x 150mm

    Diameter

    3.8mm

    Standard

    AS&NZS 4687-2007

    Packing

    Bulk Load or packing in metal pallet

    20gp load panels

    258 pieces temporary fencing panels only

    20 set load set

    250 set ( 1pcs panel+1pcs foot +1pcs clamp)

    40hc load panels

    710 pieces temporary fencing panels only

    40hc load set

    560 sets( 1pcs panel+1pcs foot +1pcs clamp)

    Weight of panel

    20.00kg

    Advantage

    Never Rusting heavy duty design

    Disadvantage

    Infill mesh are not full hot dipped galvanized maybe rusting in future

    Service life

    7-20 years

    Colors

    Silver right or electrostatic powder coated

    Materials

    Q235 Q195 PEE-GALVANIZED STEEL PIPES ROLLED PIPES

    Welding

    Two sides of temporary fencing welded by worker hand welding GMAW

    PRICE


    Portable Temporary Fence Panels , Temporary Wire Fence High StrengthPortable Temporary Fence Panels , Temporary Wire Fence High StrengthPortable Temporary Fence Panels , Temporary Wire Fence High Strength
