AS4687-2007 Anping Manufacturer CE Certificated Galvanized Temporary Fence Post
1. Specification
We are proud to launch our AS4687/2007 certified Economical priced
panels.
Materials:
Galvanized wire
Concrete blocks
Clamps
Bracing
Width: 2400mm
Height: 2100mm
Mesh infill: 60mm wide x 150mm high
Wire thickness: 3.15mm horizontal x 3.15mm Vertical.
Wire spec: HDG 28microns + (200g/m2)
Pipe specifications: 32OD X 2MM THICK; FINISH: HDG 42microns +(400g/m2)
1) Pipe thickness: 2.mm thick
2) Pipe welds: all the four ends are squashed and welded all
around; we use epoxy paint on
all our welds to safe guard against rust ,with a coat of gal paint
to make it aesthetic
3) Our infill mesh that is attached to the frame has a 10-12mm long
weld on each and every
vertical wire and a 10-12mm long weld on every second horizontal
wire (ON BOTH SIDES)
We are also proud to launch our AS4687/2007 certified panels:2100mm (H) x 2400mm (L)
Specification |
Panel Size: | 2400mm(L) x 2100mm(H) |
Frame: | 32mm O.D. |
Infill Mesh: | 4mm horizontal and vertical 150mm x 60mm spacing's |
Weight: | 24kgs |
Finish: | Hot Dipped Galvanised to Australian Standard - 42 Microns |
Welds: | Welds are hand painted with thick Zinc paint and then sprayed with
silver paint |
2. Structure
Fence Panel
Our top of the range panel is manufactured for its robustness in
remote and extreme climates. These products withstand these
environments and are best suited for the Resource and Hire
industries . Our flagship panel specification: Anti -climb mesh infill 360° weld between the vertical & horizontal pipe Horizontal pipe ends crimped for increased strength. Above Industry Benchmark in thickness of galvanising 1.94 Metre Top Horizontal Pipe for extra security
The manufacturing process uses hand welding for optimum strength
with an average of over 70 micron hot dipped galvanised finish. We
use the highest quality material specification, incorporating: |
|
Clamps
All Temporary Fencing clamps are made from hot dipped galvanised
steel ensure along life
which make them the perfect way to secure the top of the fencing
panels together.
We can also provide tamper proof nuts for extra security if
required.
|
|
Stays
Temporary fence stays are used to support the temporary fence in
high wind situations or on long runs to ensure the fence once
erected remains secure.Our specialist installation guys will access
the site and install stays if required.
Fence stays are hot dipped galvanised to Australian Standard - 42
Microns and are attached to the mesh panels by 2 clamps and
weighted down by concrete filled plastic feet. |
|
FeetAll Temporary Fencing plastic bases (feet) are a high quality,
heavy duty, long life product,
which are much smarter in appearance than the original concrete or
steel feet. Your temporary
fence will look great and be safer with these highly visible orange
coloured feet. Our feet are
more durable, will last longer, are easier to handle, and are not
prone to falling apart or chipping.
We stock a range of feet as listed below:
1. Blow moulded concrete filled plastic feet
The plastic bases stack conveniently by interlocking into the foot
below them for easy and safe
transport. The blow moulded plastic feet are filled with concrete
which make them extremely
durable as the entire concrete base is encased in plastic. This
will prolong the life of the foot
which will save you money in the long run.
2. Injection Moulded concrete filled plastic feet
These are the basic feet used by many of the temporary fencing
companies in Australia. The concrete is poured in from the
underside and the feet have two steel reinforcing rods.
|
New Type:600*228*150mm Old Type:562*245*130mm
|
3. Feature
High quality Temporary Fence Stays used to support the temporary
fence in wind areas
Hot Dipped Galvanised Tube at 32mm O.D
Specially designed for extra strength so fence stands up in winds.
Each Stay requires 3 Clamps and 3 Plastic Feet which we can provice
in a complete system.
4. Application
Construction sites
Securing sites
Road closure application
Crowd control barriers
Wind Prone Areas
Quality Standards:
AS 2423-2002 Coated Steel Wire Fencing Products for Terrestrial,
Aquatic and General Use.
AS 4687-2007 – Temporary Fencing and Hoarding
5. Detail Show
Trade Term:
Trade terms: FOB, CNF, CIF,
Payment terms: 30%T/T as deposit , L/C, Western Union,
MOQ: 50 sets
Port: TIANJIN
Sample time: 5-7days
Lead time: 15-20days depend on the final order quantity
Shipment: By sea or airport
Supply capability: 9000set/month
Sample availability: Yes
